Juki DDL-8000ASMS, or 8000ASSH, Direct Drive, High Speed, Lockstitch Machine with Auto Thread Trimmer and Voice Guidance
Medium weight model: Fashion Makers
- made for stitching of light to medium weight fabrics ; widely used in equatorial weather conditions; stitching 80 to 90% of the outfits for the lifestyle in Singapore’s climate.
- stitch well with commonly available thread sizes. Max size of up to #40 or Tex 70 or V-69 ; depending on the standard of measure of the different countries of origin.
Heavy weight model: Bags & Crafters
- made for stitching of heavy weight fabrics ; widely used in Tropical weather conditions; stitching 60 to 70% of the outfits for the lifestyle in Shanghai ; Winter climate conditions.
- greater application in stitching of Denim; Jeans ; Canvas, Leathers ; Bags ; Sofa’s and Upholstery
- stitch well with Thick threads. Max size of up to #20 or Tex 135 or V-92 ; depending on the standard of measure in the different countries of origin.
Medium Cum Heavy weight model: Best Seller.
- made for stitching of medium to heavy weight fabrics ; widely used in Equatorial, Tropical weather conditions; stitching all kinds of the outfits for the lifestyle in various climate conditions.
- greatest application in Clothing Alteration provider, stitches light weight fabrics to Leather ; home makers providing the flexibility for stitching between wider variations of fabrics; and thread types.
- stitch well with Thick and Thin threads. Max size of up to #20 or Tex 135 or V-92 ; depending on the standard of measure in the different countries of origin.
1 Year Warranty Free 1 Year Machine Training In House at Clementi
Free Installation & Delivery Local Islandwide Demo upon Delivery
JUKI's next-generation sewing system.
JUKI has launched an advanced where JUKI's digital adjustments are fully digitalized. The settings can be reproduced with total accuracy to perfectly suit the materials being sewn.
The DDL-8000A Series maintains JUKI's established seam quality and is provided with narrowed-down essential and simplified functions. It helps improve the work efficiency through operator assistance with its audio guidance.
Replacement Model of Juki DDL900B-S/-H/
| Covered by 1 year inclusive
|
|
|
Research & Development: Consult us with the possibility of each sewing machines, embroidery machines, overlock machines, ScanNCut machines and coverstitch machines that you can achieve. Show us the sewing patterns result that you desire, we will research and provide you the easiest solutions and the tools for a smooth sewing experience. |
|
| Trade-in options available and replace your old machines with upgrade program. | |
| Experience all the demo & display machines at our showroom - Bring your dedicated materials and test drive it. We will recommend the most suitable machine for you based on your profile [not the most expensive machines]. | |
|
Flexible payment method supported - Cash, PayNow [Recommended - Paperless] , PayLah [Recommended - Paperless] , Bank Transfer, NETS, Cheque Credit/Debit Cards, Installment*, and etc. |
|
| Equipment Sharing available - Wide range selection of Sewing Machines, Embroidery Machines, Software, ScanNCut Machine, Serger or Overlock Machines, Coverstitch Machines, Cylinder Bed Unison Feed Machines for Leather*, Industrial Machines etc. | |
| Warranty and Servicing from Experience in-house Professional Technicians. |
Contents
Juki DDL 8000A Series High Speed Lockstitch Machine Highlights
- DDL-8000A series M type has incorporated the Semi Dry Head with the frame that does not requires lubrications. Oil stains on products sewn, are greatly reduced, thereby improving quality and productivity.
- DDL8000A also comes with a Voice Guidance and clock function.
- With 2 USB port, sewing data can be transmitted easily and safely.
- Auto power saving by turning OFF back light, when operation panel is not in use for a period of time. (Setting time: 1 to 20 min).
- LED hand light can be set and adjustable up to 5 different levels brightness.
- Management, browsing and editing of data can be carried out on the application software .
- Data on sewing machine adjustments can be transferred to an Android tablet or phone via the Juki Smart App via NFC or micro USB. This allows all settings to be calibrate once and then replicated across all machines on one sewing line.
- Custom functions can be programed to the hand switch
- This is the newest flagship lockstitch machine from JUKI, a manufacturer which aims for genuine quality, every minute of the day.
Juki DDL 8000A Series High Speed Industrial Lockstitch Machine Features
Application- DDL-8000APMS
Direct Drive, Digital, Semi-Dry Lubrication; Medium Weight.
JUKI DDL8000ASSMNBAKK or DDL8000ASSHNBAKK
JUKI TABLE FOR DDL-8000A(R) 1070X540X40MM
Lubrication
Semi-dry
Max. Sewing Speed
5,000 sti/min
Max. Stitch Length
5mm
Needle
Bar Stroke : 30.7mm
Needle type: DBX1; Applicable Size: 9/65 to 18/110.
Lift of the presser foot
By Hand: 5.5mm, By Knee: 8.5mm to 15mm
Voice Guidance for Assisting the Operator
This sewing machine is provided as standard with the voice guidance with clock function
Production support function
The target number of products, work progress (current number of products produced, achievement rate) and the operating rate of the sewing machine are displayed on the control panel provided that the initial data have been properly set.
LED Light installed
JUKI TABLE FOR DDL-8000A(R) 1070X540X40MM
Lubrication
Semi-dry
Max. Sewing Speed
5,000 sti/min
Max. Stitch Length
5mm
Needle
Bar Stroke : 30.7mm
Needle type: DBX1; Applicable Size: 9/65 to 18/110.
Lift of the presser foot
By Hand: 5.5mm, By Knee: 8.5mm to 15mm
Voice Guidance for Assisting the Operator
This sewing machine is provided as standard with the voice guidance with clock function
Production support function
The target number of products, work progress (current number of products produced, achievement rate) and the operating rate of the sewing machine are displayed on the control panel provided that the initial data have been properly set.
LED Light installed
New Standalone USB ports that can charge phone & insert Thumbdrive
| Model name | DDL-8000AS-MS | DDL-8000AS-SH | DDL-8000AB-MS | DDL-8000AB-SH |
|---|---|---|---|---|
| Specification | Standard type | Shorter-thread remaining type | ||
| Application | Medium-weight | Heavy-weight | Medium-weight | Heavy-weight |
| Lubrication | Semi-dry | Minute-quantity lubricationy | Semi-dry | Minute-quantity lubricationy |
| Max. sewing speed | 5,000sti/min | 4,500sti/min | 5,000sti/min | 4,500sti/min |
| Max. stitch length | 5mm | |||
| Needle | DB×1 (#11) #9～#18 | DB×1 (#21) #20～#23 | DB×1 (#11) #9～#18 | DB×1 (#21) #20～#23 |
| Lift of the presser foot | By hand : 5.5mm, Auto : 1st stage 8.5mm, 2nd stage 13.0mm, By knee: 15mm | |||
